Features
Easy to Carry and Simple Operation
With a portable design, you can detect gas leaks easily. Simply place the probe near the detection area for instant confirmation of any leaks.
Capable of Detecting Various Gases
Not only can it detect gases with a significant difference in thermal conductivity from air, such as helium and carbon dioxide, but it can also detect nitrogen, which has a smaller difference and is more difficult to detect.
Dual Power Supply Design
In addition to standard battery operation, continuous operation via USB-C power supply is also possible. Even when the batteries run out, you can use it while supplying power from a PC's USB port or a mobile battery.
Note 1: USB cable is not included.
Note 2: USB power supply does not support charging functionality.
Specifications
Detection Method | Comparison of the thermal conductivity between the sample gas and the reference gas (ambient air) |
---|
Detectable Gases | Helium, Hydrogen, Carbon, Dioxide, Argon, Neon, Nitrogen, etc. |
---|
Sensitivity (Minimum Detection Limit) | [Std Range] Helium, 0.005 ml/min [High Range] Helium, 0.0005 ml/min |
---|
Display | Color LCD |
---|
Setting | Detection Range / Screen Brightness / Buzzer Volume / Auto Off |
---|
Power | 3 AA Alkaline Batteries / USB Power Supply |
---|
Usage Environment | Temperature Range: 10 - 40? Humidity Range: 10 - 80% (No Condensation) Altitude: 2000 m or below Pollution Degree: 2 |
---|
Dimensions | 52(W) x 48(D) x 170(H) mm (excluding protrusions) |
---|
Weight | Approx. 250g (excluding batteries) |
---|
